1550nm 15W قوة عالية Laser Single-mode Fiber مصدر الليزر
The 1550nm band single-wavelength laser light source (high power) uses DFB semiconductor laser chip, with high-power gain optical path module to achieve single-mode fiber high-power output, professionally designed drive circuit and TEC control to ensure safe and stable laser operation.
[سمات]
Single-mode fiber output
Multiple spectra optional
[التطبيقات]
Fiber optic sensing
Fiber laser
Laser radar
[تخصيص]
| Parameter |
Unit |
Typical Value |
Remarks |
| Wavelength |
nm |
1550nm±1nm |
1540~1565nm customizable |
| عرض خطي طيفي |
nm |
<0.1 |
Customizable |
| Sideband Suppression Ratio |
dB |
>50 |
|
| انتاج الطاقة |
W |
15 |
|
| dBm |
41 |
|
| Short-term Stability (15 minutes) |
dB |
≤ ±0.02 |
|
| Long-term Stability (8 hours) |
dB |
≤ ±0.05 |
|
| Pigtail Type |
|
SMF-28e single mode |
PM1550 PM fiber customizable |
| Pigtail Connector Type |
|
FC/APC |
|
|
Electrical and Environmental Parameters
|
نوع سطح المكتب
|
|
Control Method
|
Button
|
|
Communication Interface
|
DB9 Female
(Default not include)
|
|
مزود الطاقة
|
100~240V AC, <150W
|
|
Size
|
260(W)×320(D)×120(H)mm
|
|
درجة حرارة التشغيل Range
|
-5~+55°C
|
|
Operating Humidity Range
|
0~70%
|
