655nm 250mw وحدة الليزر الأحمر Wide voltage 5V 12V 24V قوة عالية chamber of Secrets escape laser
تحديد:
Name: 5~24V 250mW قوة عالية red laser module continously work laser Factory direct sales
Wavelength: 655nm/±5nm
انتاج الطاقة: <250mw
Size: Φ20x60mm
Material: Copper + aluminum
Surface Treatment/Color: Black (black oxide)
Service Life: continuous output, continuously working time>6000 hours
Laser Range: 500m~10000m
Laser shape/dimension: Ellipse, < Φ15mm at 10m distance(التركيز قابل للتعديل)
Circuit Control: ACC line
Work Voltage:DC=5.0~24V
Operating current: I<360mA
Work Temperature: -10 °C~+50°C
درجة حرارة التخزين: -40°C~+80°C
Security level: CLASS III B
Package List:
1* laser module(The laser mount and power supply can be choose)
Use of red light modules:
1, can be used for positioning by sight;
2, can be used for laser testing tools;
3, can be used for concentric positioning;
4, can be used for medical equipment positioning;
5, can be used for the production of signal equipment;
