Nichia 450nm 2.3W high power blue laser diode NDB7B77

Nichia 450nm 2.3W high power blue laser diode NDB7B77

تحديد：
Product name: Nichia 450nm 2.3W high power blue laser diode NDB7B77
الطول الموجي الناتج: 450nm
انتاج الطاقة: 2.3W
Pulse power：>4W
Country of origin: Japan
Operating Current: <2.2A
جهد التشغيل: 3.7-5.2V
Working temperature: 0 ~ +70℃
درجة حرارة التخزين:-10 ~ +85℃
نوع الحزمة: T05（Φ9mm）
الحياة العملية: >10,000 hours

Note:
This component sensitive to static electricity, anti-static measures do not make direct contact with the laser tube by human hand, in addition to the product must have a qualified driver circuit before work, different laser beam power with the same working voltage, but  operating current is different, the circuit of the tube drive current needed to control in a safe range, otherwise it will affect life expectancy.

This is a special product, before shipment to ensure the good quality and brand new, once sold, do not be warranty and refund!
